| CPU |
1. LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors |
|
2. L3 cache varies with CPU |
|
(Please refer “CPU Support List” for more information.) |
| Chipset |
1. Intel® B760 Express Chipset |
| Memory |
1. Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules |
|
2. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory |
|
3. Dual channel memory architecture |
|
4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
|
5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
|
6. Support for Extreme Memory Profile (XMP) memory modules |
|
(Please refer “Memory Support List” for more information.) |
| Onboard Graphics |
Integrated Graphics Processor-Intel® HD Graphics support: |
|
1. 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz |
|
2. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz |
|
* Support for HDMI 2.0 version and HDCP 2.3. |
|
3. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
|
* Support for DisplayPort 1.2 version and HDCP 2.3 |
|
(Graphics specifications may vary depending on CPU support.) |
|
Support for up to 3 displays at the same time |
| Audio |
1. Realtek® Audio CODEC |
|
2. High Definition Audio |
|
3. 2/4/5.1/7.1-channel |
|
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
|
4. Support for S/PDIF Out |
| LAN |
1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Expansion Slots |
CPU: |
|
1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 |
|
Chipset: |
|
1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Storage Interface |
CPU: |
|
1. 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) |
|
Chipset: |
|
1. 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) |
|
2. 4 x SATA 6Gb/s connectors |
|
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB |
Chipset: |
|
1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support |
|
2. 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) |
|
3. 2 x USB 2.0/1.1 ports on the back panel |
|
Chipset USB 2.0 Hubs: |
|
1. 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Internal I/O Connectors |
1. 1 x 24-pin ATX main power connector |
|
2. 1 x 8-pin ATX 12V power connector |
|
3. 1 x CPU fan header |
|
4. 3 x system fan headers |
|
5. 1 x addressable LED strip headers |
|
6. 1 x RGB LED strip headers |
|
7. 2 x M.2 Socket 3 connectors |
|
8. 4 x SATA 6Gb/s connectors |
|
9. 1 x front panel header |
|
10. 1 x front panel audio header |
|
11. 1 x S/PDIF Out header |
|
12. 1 x USB 3.2 Gen 1 header |
|
13. 2 x USB 2.0/1.1 headers |
|
14. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
|
15. 1 x serial port header |
|
16. 1 x Q-Flash Plus button |
|
17. 1 x reset jumper |
|
18. 1 x Clear CMOS jumper |
| Back Panel Connectors |
1. 2 x USB 2.0/1.1 ports |
|
2. 1 x PS/2 keyboard/mouse port |
|
3. 1 x D-Sub port |
|
4. 1 x HDMI port |
|
5. 1 x DisplayPort |
|
6. 3 x USB 3.2 Gen 1 ports |
|
7. 1 x USB Type-C® port, with USB 3.2 Gen 1 support |
|
8. 1 x RJ-45 port |
|
9. 3 x audio jacks |
| I/O Controller |
1. iTE® I/O Controller Chip |
| H/W Monitoring |
1. Voltage detection |
|
2. Temperature detection |
|
3. Fan speed detection |
|
4. Water cooling flow rate detection |
|
5. Fan fail warning |
|
6. Fan speed control |
|
* Whether the fan speed control function is supported will depend on the fan you install. |
| BIOS |
1. 1 x 128 Mbit flash |
|
2. Use of licensed AMI UEFI BIOS |
|
3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
1. Support for GIGABYTE Control Center (GCC) |
|
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
|
2. Support for Q-Flash |
|
3. Support for Q-Flash Plus |
| Bundled Software |
1. Norton® Internet Security (OEM version) |
|
2. LAN bandwidth management software |
| Operating System |
1. Support for Windows 11 64-bit |
|
2. Support for Windows 10 64-bit |
| Form Factor |
1. Micro ATX Form Factor; 24.4cm x 22.5cm |
